Advantages
The box is sturdy and durable
Waterproof and dustproof
Long lifespan
Source factory
Customization supported
Worry-free after-sales service
Technical specification
Material: | 304 stainless steel for body and door |
Mounting plate: | Galvanized sheet or 304 stainless steel |
Thickness: | Body and Door 1.2mm, mounted plate:1.5mm; Height greater than 600mm, Body and Door 1.5mm, mounted plate:2.0mm |
Surface Treatment: | Brushed or powder coated |
Protection Grade: | IP65 |
Against Mechanical Impacts: | IK10 |
Color: | RAL7032, RAL7035 or customized |
Standard Configuration: | Housing, door, mounting plate, lock, seal strip, grounding set |
Dimensions
More dimensions and Nonstandard products are customizable
| No | Type no | Height (mm) | Width | Depth | Enclosure&door | Mounting plate（mm) |
| (mm) | (mm) | (mm） | ||||
| 1 | HSSID040302 | 400 | 300 | 200 | 1.2 | 1.5 |
| 2 | HSSID0403025 | 400 | 300 | 250 | 1.2 | 1.5 |
| 3 | HSSID050302 | 500 | 300 | 200 | 1.2 | 1.5 |
| 4 | HSSID0503025 | 500 | 300 | 250 | 1.2 | 1.5 |
| 5 | HSSID050402 | 500 | 400 | 200 | 1.2 | 1.5 |
| 6 | HSSID0504025 | 500 | 400 | 250 | 1.2 | 1.5 |
| 7 | HSSID060402 | 600 | 400 | 200 | 1.2 | 1.5 |
| 8 | HSSID0604025 | 600 | 400 | 250 | 1.2 | 1.5 |
| 9 | HSSID070502 | 700 | 500 | 200 | 1.5 | 2 |
| 10 | HSSID0705025 | 700 | 500 | 250 | 1.5 | 2 |
| 11 | HSSID070602 | 700 | 600 | 200 | 1.5 | 2 |
| 12 | HSSID0706025 | 700 | 600 | 250 | 1.5 | 2 |
| 13 | HSSID080602 | 800 | 600 | 200 | 1.5 | 2 |
| 14 | HSSID0806025 | 800 | 600 | 250 | 1.5 | 2 |
| 15 | HSSID080802 | 800 | 800 | 200 | 1.5 | 2 |
| 16 | HSSID0808025 | 800 | 800 | 250 | 1.5 | 2 |
| 17 | HSSID100802 | 1000 | 800 | 200 | 1.5 | 2 |
| 18 | HSSID1008025 | 1000 | 800 | 250 | 1.5 | 2 |
